Features a disc specific elliptical profile designed with aerodynamics and weight as key factors.  Specifically tuned to be aerodynamically paired with 23-28c road tires, though a 20mm inner width compliments even the most voluminous gravel and ‘cross tires.

Tubeless ready using 24mm Velotape.

Tight tolerances require the use of a low profile rim tape like  to avoid tire installation issues.  Veloplugs are not recommended on Aileron rims.

700c is available in 36 and 40 hole drillings for our  builds.

Specs

• RIM SIZE: 700c or 650b
• WIDTH:25mm
• HEIGHT:28mm
• OPTIMAL TIRE WIDTH:25mm - 47mm
• TIRE INTERFACE:Clincher / Tubeless
• VALVE:Presta 41 - 55mm
• BEAD SEAT DIAMETER (BSD):622
• EFFECTIVE RIM DIAMETER (ERD):584
• WEIGHT:465g

• 24 spoke: Black, Silver, White, Polished
• 28 spoke: Black, Silver, White, Polished
• 32 spoke: Black, Silver, White, Polished
• 36 spoke: Black, Silver
• 40 spoke: Black
